Intermediate Algebra: Functions and Graphs

Investigation 3.1. Falling.

Suppose you drop a small object from a height and let it fall under the influence of gravity. Does it fall at the same speed throughout its descent? The diagram shows a sequence of photographs of a steel ball falling onto a table. The photographs were taken using a stroboscopic flash at intervals of 0.05 second, and a scale on the left side shows the height of the ball, in feet, at each interval.

1. Complete the table showing the height of the ball at each 0.05-second interval. Measure the height at the bottom of the ball in each image. The first photo was taken at time \(t=0\text{.}\)

   \(t\)	\(0\)	\(0.05\)	\(0.10\)	\(0.15\)	\(0.20\)	\(0.25\)	\(0.30\)	\(0.35\)	\(0.40\)	\(0.45\)	\(0.50\)
   \(h\)	\(\)	\(\)	\(\)	\(\)	\(\)	\(\)	\(\)	\(\)	\(\)	\(\)	\(\)

2. Plot the points in the table. Connect the points with a smooth curve to sketch a graph of height versus elapsed time. Is the graph linear?

3. Use your graph to estimate the time elapsed when the ball is 3.5 feet high, and when it is 1 foot high.

4. What was the change in the ball’s height during the first quarter second, from \(t=0\) to \(t=0.25\) ? What was the change in the ball’s height from \(t=0.25\) to \(t=0.50\) ?

5. Add to your graph a line segment connecting the points at \(t=0\) and \(t=0.25\text{,}\) and a second line segment connecting the points at \(t=0.25\) and \(t=0.50\text{.}\) Compute the slope of each line segment.

6. What do the slopes in part (5) represent in terms of the problem?

7. Use your answers to part (4) to verify algebraically that the graph is not linear.

Investigation 3.2. Perimeter and Area.

Do all rectangles with the same perimeter, say 36 inches, have the same area? Two different rectangles with perimeter 36 inches are shown. The first rectangle has base 10 inches and height 8 inches, and its area is 80 square inches. The second rectangle has base 12 inches and height 6 inches. Its area is 72 square inches.

1. The table shows the bases of various rectangles, in inches. Each rectangle has a perimeter of 36 inches. Fill in the height and the area of each rectangle. (To find the height of the rectangle, reason as follows: The base plus the height makes up half of the rectangle’s perimeter.)

   Base	Height	Area
   \(10\)	\(8\)	\(80\)
   \(12\)	\(6\)	\(72\)
   \(3\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(14\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(5\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(17\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(19\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(2\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(11\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(4\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(16\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(15\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(1\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(6\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(8\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(13\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)
   \(7\)	\(\hphantom{0000}\)	\(\hphantom{0000}\)



2. What happens to the area of the rectangle when we change its base? On the grid above, plot the points with coordinates (Base, Area). (For this graph we will not use the heights of the rectangles.) The first two points, \((10, 80)\) and \((12, 72)\text{,}\) are shown. Connect your data points with a smooth curve.

3. What are the coordinates of the highest point on your graph?

4. Each point on your graph represents a particular rectangle with perimeter 36 inches. The first coordinate of the point gives the base of the rectangle, and the second coordinate gives the area of the rectangle. What is the largest area you found among rectangles with perimeter 36 inches? What is the base for that rectangle? What is its height?

5. Describe the rectangle that corresponds to the point \((13, 65)\text{.}\)

6. Find two points on your graph with vertical coordinate 80.

7. If the rectangle has area 80 square inches, what is its base? Why are there two different answers here? Describe the rectangle corresponding to each answer.

8. Now we’ll write an algebraic expression for the area of the rectangle in terms of its base. Let \(x\) represent the base of the rectangle. First, express the height of the rectangle in terms of \(x\text{.}\) (Hint: If the perimeter of the rectangle is 36 inches, what is the sum of the base and the height?) Now write an expression for the area of the rectangle in terms of \(x\text{.}\)

9. Use your formula from part (8) to compute the area of the rectangle when the base is 5 inches. Does your answer agree with the values in your table and the point on your graph?

10. Use your formula to compute the area of the rectangle when \(x=0\) and when \(x=18\text{.}\) Describe the “rectangles” that correspond to these data points.

11. Continue your graph to include the points corresponding to \(x=0\) and to \(x=18\text{.}\)
